AutoLens 1.5 m
Looking

Illustration of Clocked at work, not camera footage: a dog runs along the footpath at night, a box locks on to it and the estimate reads 31 km/h, plus or minus 5. A runner, a cyclist and a car pass too, and you can switch the lock between them.

Illustration, not camera footage. Real readings depend on the scene: see accuracy and limitations.

Camera speed estimator

Speed, estimated.

Hold your phone steady, side-on to a road or path. Clocked detects passing vehicles, bikes and runners on the phone and estimates their speed from the camera’s geometry, with a ± range on every reading.

  • No ads
  • No accounts
  • No subscriptions
Get it on Google PlayTry Clocked on iPhone with TestFlight

On Google Play, and on iPhone through TestFlight. Free to download and use. Pro is an optional in-app upgrade.

How it works

Detect, locate, fit a line.

Every step runs on your phone, frame by frame. The maths is camera geometry.

  1. Detect

    An object-detection model on your phone boxes cars, trucks, buses, motorcycles, bikes, runners and walkers in each camera frame. Clocked follows the moving one nearest the middle. Tap another box to switch.

  2. Locate

    The camera’s lens data turns each point in the picture into a direction, and the motion sensors give the phone’s tilt for every frame. The lens height and the point where wheels or feet meet the ground give the distance, or you type a measured one.

  3. Fit

    Positions from many frames, each with the camera’s own timestamp, are fitted to a line. Distance per second is the estimated speed, shown with its ± range: 52 km/h ±6.

Modes

Three ways to measure, all free.

Each mode gets the distance a different way. Start in Auto, and switch when the scene calls for it.

Auto

Free

Ground plane, lens height learned

Clocked learns the lens height from the cars and people that pass, using their typical size, then works out the distance from where things meet the ground. Until one has passed it asks for one, and it marks a reading “~” until a second agrees. Or set the height by hand.

Known distance

Free

You measure the distance

Type the measured distance to the path, and Clocked turns the target’s angle into its position along it. Passes heading toward or away from you are refused.

Stopwatch

Free

Time it between two marks

Tap as a target passes two marks a known distance apart. Plain timing, no camera: 25 m in 3.1 s is 29 km/h.

Two-mark calibration, also free: aim at two marks at measured distances and Clocked solves the lens height and the camera’s tilt together, narrowing the ± range.

Clocked Pro

More from every pass.

Clocked Pro is an optional in-app upgrade. Every firm reading is logged on your phone, free or Pro. Pro adds record and replay, sharing, zoom, statistics, export, alerts, box styles, snapshots and auto snapshots.

Pro box colours against a 50 km/h limit: the locked car reads 61, over the limit, so its box is red. The other cars get faint boxes; tap one to switch to it. 61 LIMIT 50
UnderCloseOver the limit you set

Analyse Example session

Passes
214
Average
41km/h
85th percentile
48km/h
Over 50
10%
Passes per hour, 7 am to 7 pm, peaking at 8 am and 5 pm.

85th percentile: the speed 85 in 100 passes stay at or under. Illustrative numbers.

  • Record and replay

    Record a pass, then replay it at quarter, half or full speed or frame by frame, and tap any vehicle, bike or runner in the clip for its estimate.

  • Box colours and styles

    Set a limit and the locked box turns green, amber or red against it. Draw it as corners, a box or a dot.

  • Speed alert

    A tone and a red badge when a reading passes the limit you set.

  • Analyse

    Your logged passes as count, average, median, 85th percentile, % over your limit, a histogram and an hourly chart, with filters.

  • CSV export

    Send the log to a spreadsheet and slice it your way.

  • Speed-stamped snapshot

    A photo of the pass stamped with the estimated speed, its ± and the words “An estimate”.

  • Auto snapshots

    Turn it on and Clocked saves a snapshot of each pass over your limit, up to as many per session as you choose. Off until you do.

  • Zoom lock-on

    Pinch, or tap 2x or 3x, to fill the picture with a pass further down the road. The maths follows the zoom.

  • Daily previews.

    Analyse, snapshots and zoom each have a short preview once a day.

  • Optional.

    Pro is an in-app upgrade. Every way to measure, and calibration, stays free.

Replay it, then share it

Open a recording and Play runs it at quarter, half or full speed, while Next frame steps it one frame at a time. Tap the vehicle, bike or runner you want for its estimate, then pick a different one if you like.

Share clip sends the pass with its box, the estimated speed and its ± range drawn on. In Recordings, Share photo sends a snapshot.

Clocked's Replay controls under a 19-second recording: the hint Play, then tap an object, a timeline, Play and Next frame, playback at 0.25x, 0.5x or 1x, then Share clip, a button to pick another object, and Snapshot.
The Replay controls in Clocked 2.1

Accuracy and limitations

An estimate, not a precision instrument.

Every reading is an estimate. The ± beside it is a live uncertainty estimate from the fit, the tilt sensor, the lens height or distance, and the lens data: a model, not a guaranteed error limit. It works best like this:

  • Brace the phone

    Lean on a post, a wall or a fence. A braced phone gives the tightest ±.

  • Side-on

    Stand so it crosses the frame, not heads straight for you.

  • 10 to 30 m away

    Close enough to see it clearly, far enough to watch it move.

  • Give it the scale

    Let a car or person pass so Auto learns the lens height, or set it, calibrate with two marks, or measure the distance.

Top-down view. The phone stands back from the road, 10 to 30 metres away, with traffic crossing its view side-on. Traffic heading straight at the phone is harder to read. 10 m 30 m SIDE-ON: BEST YOU HEAD-ON:HARDER

Clocked is not a certified or calibrated measuring device. Its readings are estimates for curiosity, sport and informal traffic surveys, and must not be used for legal or safety-critical purposes, or to make claims about anyone’s driving.

It works poorly when the target heads toward or away from you, the phone shakes, pans or tilts, the target is far away, small, partly hidden or poorly lit, the road slopes or the ground is uneven, or an unusual size (a child, a tall truck) misleads the automatic lens height.

When it detects a problem, Clocked says so instead of showing a confident number: “Hold steady”, “Level the phone”, “Too far”, “Coming toward you: low accuracy” or “No reading: sizes don’t match the lens height”.

Stay safe. Stand somewhere safe and watch your surroundings. Never step into traffic to place a mark or take a reading, and never use Clocked while driving or cycling.

FAQ

Fair questions.

How accurate is it?

Every reading is an estimate, and the ± beside it is a live uncertainty estimate: a model, not a guaranteed error limit. It narrows when the phone is braced, the target crosses side-on about 10 to 30 m away, and the lens height is learned, set or calibrated, or the distance is measured. Clocked is not a certified or calibrated measuring device, so its readings are not for legal or safety-critical use.

What can it measure?

Cars, trucks, buses, motorcycles, bicycles, runners and walkers, plus larger animals such as dogs. In Auto, a dog or a bike on its own gets a reading once a car or person has passed, or once the lens height is set or calibrated. Targets that cross the frame side-on work best; ones coming straight at you or going straight away are harder, and Clocked says so.

How does Auto know the distance?

From the lens height above the road and the point where the wheels or feet meet the ground. Clocked learns the lens height automatically from the cars and people that pass, using their typical size, and marks a reading “~” until a second one agrees. You can also set the height by hand in Fine tuning, or measure it with two-mark calibration, which is free.

km/h or mph?

Both. Clocked starts in the unit your region uses, and you can switch any time.

What’s free, and what’s in Pro?

Free: Auto, Known distance and the stopwatch, two-mark calibration, tap to switch target, km/h or mph, and a log of every firm reading on your phone. Clocked Pro is an optional in-app upgrade that adds record and replay, zoom lock-on, Analyse, CSV export, speed alerts, box colours and styles, speed-stamped snapshots and auto snapshots. Analyse, snapshots and zoom each have a short daily preview.

What happens to the camera picture?

Camera frames are processed on your phone to estimate speed. Your settings and pass log are kept on your phone. We receive anonymous usage stats.

Where can I get it?

Clocked is on Google Play, and on iPhone through TestFlight: tap a badge on this page to install it. There’s nothing to sign up for here: no mailing list and no account.

Get Clocked

Get it on Google Play.

Free to download and use: Auto, Known distance, the stopwatch and two-mark calibration. Clocked Pro is an optional in-app upgrade.

Get it on Google PlayTry Clocked on iPhone with TestFlight
